WT SFP Transceiver Module,WT-SFP+-ER,10GBase-ER SFP+ Transceiver, 10G 1550nm SMF, up to 40 km,Commercial grade

US$
205.71
 FS P/N: WT-SFP+-ER
99Sold 99Reviews 185Questions
shipping
Shipped from Shenzhen HQ Warehouse
delivery
Free Shipping
Products and Project Inquiry
30-Day Returns
30-Day Returns
30-Day Exchange
30-Day Exchange
3-Year Warranty
3-Year Warranty
-
+
Product Highlights

  • SFP+ package with LC connector

  • 1550nm EML Laser and PIN photo detector

  • Up to 40km transmission on SMF

  • Power dissipation < 1.5W

  • LVPECL compatible data input/output interface

  • Low EMI and excellent ESD protection

  • laser safety standard IEC-60825 compliant

  • Compatible with RoHS

  • Compatible with SFF8472


Center Wavelength1550nm
Storage Temperature-40－85℃
Operating Relative Humidity5-95%
Supply Voltage3.3V
Power Dissipation<1.5W
Data Rate10.3125Gbps
Average Output Power-2-4dBm
Extinction Ratio（Er）>3.5dB
Receiver Sensitivity（Rsen）≥-15dBm
DDMSupported
ompatible brandsCisco\HP\H3C\HUAWEI
Warranty3 Years


  • Connectivity Solutions
  • Features

  • SFP+ package with LC connector

  • 1550nm EML Laser and PIN photo detector

  • Up to 40km transmission on SMF

  • Power dissipation < 1.5W

  • LVPECL compatible data input/output interface

  • Low EMI and excellent ESD protection

  • laser safety standard IEC-60825 compliant

  • Compatible with RoHS

  • Compatible with SFF8472

  • Reviews (99)
No reviews yet
  • Resources
WT-SFP+-ER
WT SFP Transceiver Module,WT-SFP+-ER,10GBase-ER SFP+ Transceiver, 10G 1550nm SMF, up to 40 km,Commercial grade

WT-SFP+-ER

US$205.71
