WT SFP Transceiver Module,WT-PS-E53-20L-D,155M SFP BD Transceiver, Tx1550nm & Rx1310nm, 20km,Commercial grade

US$
6.00
 FS P/N: WT-PS-E53-20L-D
123Sold 99Reviews 185Questions
shipping
Shipped from Shenzhen HQ Warehouse
delivery
Free Shipping
Products and Project Inquiry
30-Day Returns
30-Day Returns
30-Day Exchange
30-Day Exchange
3-Year Warranty
3-Year Warranty
-
+
Product Highlights

  • SFP package with LC connector

  • 1310nm FP Laser and 1550nm PIN photodetector

  • 1550nm FP Laser and 1310nm PIN photodetector

  • Up to 20Km transmission on SMF

  • +3.3V single power supply

  • LVPECL compatible data input/output interface

  • Low EMI and excellent ESD protection

  • laser safety standard IEC-60825 compliant

  • Compatible with RoHS

  • Compatible with SFF8472


Center Wavelength1310/1550nm
Storage Temperature-40－85℃
Operating Relative Humidity5-95%
Supply Voltage3.3V
Power Dissipation<1W
Data Rate155Mbps
Average Output Power-15－-3dBm
Extinction Ratio（Er）>8dB
Receiver Sensitivity（Rsen）≥-32dBm
DDMSupported
ompatible brandsCisco\HP\H3C\HUAWEI
Warranty3 Years


  • Connectivity Solutions
  • Features

  • SFP package with LC connector

  • 1310nm FP Laser and 1550nm PIN photodetector

  • 1550nm FP Laser and 1310nm PIN photodetector

  • Up to 20Km transmission on SMF

  • +3.3V single power supply

  • LVPECL compatible data input/output interface

  • Low EMI and excellent ESD protection

  • laser safety standard IEC-60825 compliant

  • Compatible with RoHS

  • Compatible with SFF8472


  • Reviews (99)
No reviews yet
  • Resources
WT SFP Transceiver Module,WT-PS-E53-20L-D,155M SFP BD Transceiver, Tx1550nm & Rx1310nm, 20km,Commercial grade

WT-PS-E53-20L-D

US$6.00
