| Applicable Standards | IEEE 802.3 10BaseT IEEE 802.3u 100BaseT IEEE 802.3z 1000BaseFX and 1000BaseT IEEE 802.3af/802.3at POE IEEE 802.3x flow control IEEE 802.1d-2004 STP protocol IEEE 802.1w RSTP protocol IEEE 802.1p Qos IEEE 802.1q VLAN SNMPv1/v2c HTTP, DHCP Client | Physical Properties | Enclosure: Aluminum enclosure, IP40-rated protection Size: 142 × 116 × 51 mm Weight: 850 g Mounting method: Guide rail type |
| Switching Feature | Qos queue: 8 VLAN-ID: 1-4094 Back plane bandwidth: 20 Gbps List of MAC addresses: 8K Message buffer size: 4.1Mbit | Environmental Restrictions | Working temperature: -40 ~ 85°C (-40 ~ 185°F) Storage temperature: -40 ~ 85°C (-40 ~ 185°F) Relative ambient humidity: 5 ~ 95% (non-condensing) |
| Ports | Fiber port: 1000 Mbps Copper port: 10/100/1000 Mbps self-adaptive, Full/Half duplex mode, MDI/MDI-X supported. | Standards & Certification | IEC61000-4-2(ESD) level 4, IEC 61000-4-4 (EFT) level 4, IEC 61000-4-5(Surge) level 4 Anti-vibration performance: IEC 60068-2-6 Shock resistance: IEC 60068-2-27 Free fall: IEC 60068-2-32 Note: Please go to the official website of Wintop Optical for the latest certification status. |
| LED Indicator | P1, P2, RUN, L/A,POE | MTBF | Mean Time Between Failures: 500,000 hours |
| Power Requirements | Input voltage: DC 48~57 V (redundancy) Full-load power consumption: 7W (excluding POE) | Warranty | Quality assurance: 5 years |
Support the 802.1Q VLAN of 4K range
IGMP Snooping for filtering multicast traffic
Support the web page management configuration; and hardware one-button recovery of factory settings
Dual power inputs with a wide range of 48-57 VDC
Forced Hundred Megabit and Gigabit rate of fiber port facilitates connection with fiber equipment
Dial switches enable ringing, port isolation and forced 10M
QoS (IEEE 802.1p and DSCP) improves data transfer certainty
Port mirroring feature assists in online troubleshooting and allows for data analysis and monitoring
Port aggregation increases bandwidth and enhances the reliability of network connection
Spanning Tree Protocol STP/RSTP ring redundancy
Port loop detection reduces the impact of access loop on the entire network
VIP channel 1-2 ports (POE port QOS priority)
RS6310-2GF8GT-8POE
